midi DATA LOGGER GL240

PC (APS) SUPPORT midi LOGGER GL240 Series

SOFTWARE FOR PC (APS) >>

SOFTWARE FOR SMART DEVICE (GL-CONNECT) ANDROID/IOS >>

Supports up to maximum 1000 channels

The software allows to control up to 10 units of GL series or 1000ch max.

The application software will connect the GL Series Data Loggers to the PC. Software controls the setting, recording, and management of the recorded data.

3-TYPES OF THE MEASUREMENT DISPLAY SCREEN

CAPTURED-DATA CAN BE WRITTEN DIRECTLY TO AN EXCEL FILE

Real time streaming data can be displayed on excel.

DATA CAPTURING SCHEDULE CAN BE SET VISUALLY AND INTUITIVELY

Set recording schedule easily by dragging the mouse and selecting date and time

CHECKING TIME-ZONE OF MULTIPLE MEASUREMENT

The sampling time zone of multiple measurement files can be checked at once.

EASILY FIND A DEVICE TO CONNECT WITH PC

RECORDING SYNCHRONIZATION WITH MULTIPLE DEVICES AND CREATE A SINGLE FILE FOR ALL UNITS

3 Files are created regarding to 3 units of GL840 or GL240. And 1 file as a group is created.

SOFTWARE SPECIFICATIONS FOR PC


          Item
          Description

        Model name
        GL100_240_840-APS

        Supported OS
        Windows 10, 8.1, 8, 7, Vista    (32/64-bit edition)

        Supported device
        GL840 (USB, Ethernet,    WLAN), GL240 (USB, WLAN), GL100 (USB, WLAN)

        Functions
        Control the GL series,    Real-time data capture, Replay data, and Data format conversion

        Supported units    & channels
        Up to 1000 channels total,    Up to 4 groups (number of units is limited by model)

        Settings control
        Input condition, Capturing    condition, Trigger/Alarm condition, Report, etc.

        Capturing    data
        Saved to PC
        Saves captured data in real    time (in GBD binary or CSV format)

        Saved to GL unit
        Saves to the SD memory card    (in GBD binary or CSV format)

        Displayed    information
        Y-T    waveform, Digital values, Report, X-Y graph (specified period of data,    data

          reply only), Two displays for the current and past data, and Statistical    calculation

        File    operation
        Converting    data format to CSV from GBD binary, merge multiple data files

          in the time axis or as an additional channel

        Warning function
        Send e-mail to the    specified address when the alarms occur

        Statistical    calculation
        Maximum, Minimum, and    Avarage during data capturing

        Report function
        Creates the daily or    monthly report automatically

FOR SMART DEVICE (GL-CONNECT) ANDROID/IOS

SUPPORT midi DATA LOGGER GL240 Series

Android (4.1-6.0)

iOS 7-9 (up to 9.3.4)

SOFTWARE SPECIFICATIONS FOR SMART DEVICE


          Item
          Description

        Model name
        GL-Connect

        Supported OS
        Android 4.1 to 6.0, iOS 7/8/9 (up to 9.3.4)

        Supported    device
        GL840 (WLAN), GL240 (WLAN), GL100 (WLAN)

        Functions
        Control the GL series,    Display measured data in waveform or digital value

        Supported    units
        Up to 10 units

        Settings    control
        Start/Stop, Sampling    interval

        Capturing data
        Saves captured data in the    GL main body (data cannot be saved in the smart device)

        Displayed    information
        Data captured in real time    by digital value, Replay the data stored in the GL body by the waveform
