GRAPHTEC MIDI DATA LOGGER GL240 STANDALONE ALL CHANNEL ISOLATED

GL240 FEATURES

  • 4.3 inch wide TFT color LCD screen

  • Three types of power source: AC, DC (B-514)*, rechargeable battery pack (B-569)*

  • Extended memory capacity using SD cards (SDHC compatible up to 32GB)*

  • Max sampling interval up to 10ms/1 ch. 100ms for all 10 channels

  • All channels isolated

  • Alarm output ports up to 4 channels

  • Logic/Pulse signal input port up to 4 channels

  • Flexible input system for voltage, temp, humidity, pulse and logic signals

  • Smartphone, remote access monitoring capability

  • Wireless LAN using optional* WLAN Unit B-568 for remote monitoring and data logging

       *Optional accessories not included

GL240 is a 10 channel comprehensive data logger and the best value market leader. This compact, comprehensive data logger accepts voltage, temperature, humidity, pulse and logic signals. Channel-to-channel isolation means wiring errors or overloaded channels do not affect neighboring channels and we focus our effort on providing you accurate data you can count on.

Industries Benefiting from the GL240:

  • Aftermarket Automotive Tuning

  • Agriculture and Food Manufacturing

  • Greenhouse and Hydroponics

  • Construction and Civil engineering

  • Machinery Manufacturing

  • Automotive Industry

  • Aerospace and Military Industry

  • Utilities / Gas and Electric

  • Battery Manufacturing

  • Electrical Appliance and Office Equipment

  • Electrical Service and Maintenance Companies

  • Food Processing

  • Rail Transportation

  • Raw Materials and Components Manufacturing

  • Research and Development

How to install the B-569 batteries with the new protective rubber cover




WIRELESS MEASUREMENT USING WIRELESS LAN (optional)

GRAPHTEC MIDI DATA LOGGER GL240 WIRELESS MEASUREMENT USING WIRELESS LAN



Wireless LAN option enables the wireless communication with other device.  When GL240 is set as a station, PC and smart devices can access the GL240 directly using the Wireless LAN module.  B-568 wireless module option is required.

COMBINING GL100-WL AND GL240

GRAPHTEC MIDI DATA LOGGER GL240 COMBINED WITH GL100-WL



GL100-WL can now be connected to the GL240 as a remote sensor using the WLAN feature.  GL240 supports 1 unit of the GL100-WL, with real time recording.  The measured value from the GL100-WL will appear on the GL240 display wirelessly and records in a single file along with the measurement value from the GL240 main inputs.  Additional measurements for acceleration/vibration, CO2, light/UV, temp, humidity, and AC current can be wirelessly monitored.

ALL CHANNEL ISOLATED/UNIVERSAL INPUT

GRAPHTEC GL240 ALL CHANNEL ISOLATED UNIVERSAL INPUT VOLTAGE TEMPERATURE HUMIDITY PULSE LOGIC



Channel to Channel isolation is the highlight of the Graphtec data loggers.  Along with its compact footprint, GL240 contains an isolated input system which ensures that signals are not corrupted by inputs from other channels.

MAXIMUM SAMPLING INTERVAL OF UP TO 10MS

GRAPHTEC GL240 SAMPLING 10MS





Provides faster sampling rate of 10ms for a single channel voltage measurement.  Simultaneous scanning feature allows up to 100 ms when measuring all 10-channels.

BUILT-IN 4GB FLASH MEMORY WITH SD CARD SUPPORT

GRAPHTEC DATA LOGGER GL240 BUILT IN 4 GB FLASH MEMORY WITH SD CARD SUPPORT

The new GL series enables reliable long term measurment with its built-in 4GB flash memory and SD card slot for external storage devices.




USEFUL FUNCTIONS

GRAPHTEC DATA LOGGER GL240 USEFUL FUNCTIONS INTEGRATION ALARM 3 WAY DRIVE DISPLAY NETWORK



Various functions, such as a bar chart data display, alarm output function, and networking features, are available in the GL240 to assist convenient and helpful features for additional data logging capability.
