CE6000-120AKZ
The CE6000-120 AKZ delivers best in class performance on a variety of automotive customizing media from window tint to paint protection film.
On the job, the CE6000-120AKZ offers real cost/performance advantages over other brands of cutting plotters. With faster cutting speeds and higher cutting force, you’ll have the flexibility to handle a wider range of material. The USB 2.0 high speed data interface or RS232C Serial Port ensures a reliable connection to the computer, either on a Mac or Windows PC. The CE6000 comes with Graphtec Studio design software for Windows and Mac, plus Cutting Master 3Production Manager and Plug-in for the latest versions of CorelDraw® and Adobe® Illustrator on Windows; Adobe® Illustrator plug-in for Macintosh systems.
Auto Registration Mark Sensor (ARMS) 4-point, dual-axis skew correction The CE6000120 AKZ comes installed with antistatic cords for front and rear which reduces the static electricity that is so common with tint films that can restrict media movement. Cutting vinyls and contour cutting pre-printed media from most any laser, solvent and water-based inkjet are what Graphtec cutting plotters are famous for.
The CE6000–120 AKZ comes installed with Anti–Static Cords for front and rear which reduces the static electricity that is so common with tint films that can restrict media movement. Plus, its High–End Servo Motor delivers accurate cutting (up to 450 g) of heavy materials such as paint protection films - making it the perfect solution to any tint and paint protection shop that wants to explore the vehicle graphics world. Each unit also includes: floor stand, dual media catch basket for dust-free cutting and anti-static cords.
Models
CE6000-120 AKZ include:
Anti-static string
Media catch basket
2 year standard warranty
Features
CUTTER FOR AUTOMOTIVE AFTERMARKET
WITH STAND, MEDIA CATCH BASKET,
ANTI-ELECTROSTATIC STRINGS AND MAGNET
3 inch wide user-friendly LCD control Panel
Setting can be easily configured using the large LCD (3.7-inches, 240x128 dots) and tactile control panel. It is also icon driven and supports 10 languages.
High adaptability to the operating environment
The design of the media feed system ensures that loaded media is acclimated to the ambient temperature and humidity before plotting or cutting. The user-selectable media pre-feed function sets two outer tracks, enhancing media handling. Together, these two media feed elements ensure reliable cutting and plotting quality within the desired operating environment.
New design with ease of use
All operations such as media loading, unloading, and menu settings can be conveniently done from the front of the machine. For added convenience, heavy media can be loaded on the low position of the media stocker as well. This front-loading configuration also saves valuable production space.
Easy to use in simple operation mode
Two set up menus: simple and normal are available an can be chosen by the operator as desired.
Enhanced speed when perforation cutting
Innovative features include maximum cutting speeds of 39 ips and with a maximum cutting force of 450g. It also features an easy to use menu navigation system with eight groups of preset conditions which facilitates instantaneous recall of pre-programmed job-specific plotter setups.
Tri-port connectivity (USB, parallel and serial) makes the CE6000 series compatible with virtually any computer configuration.
Perforation cutting is performed by controlling the cutting force instead of blade up/down movements - dramatically increasing throughput. The force is controlled by the design software using a new command.
Reliable tracking
The built-in front control panel provides complete parameter control including eight preset cutting conditions, as well as advanced features like tangential control mode, down force offset, pen up speed, blade wear monitoring and more. With a 25 pin RS-232C or the High Speed USB 2.0 control interface, the CE6000 is compatible with legacy computer systems as well as the latest PCs available now and for several years to come.
The number of push rollers has been increased to five; with the three inner rollers having two pressure settings (low and normal) to prevent media lifting and to suit a wider range of substrates. A media sheet guide is also included to reduce static and to improve long length tracking. These two new additions ensure a more stable media feed and higher productivity.
| Item | CE6000-120 AKZ | |||
|---|---|---|---|---|
| Configuration | Grit roller with digital servo drive system | |||
| Maximum cutting area (W x L) | 48 in x 164.04 ft (1213 mm × 50 m) (*1) | |||
| Cutting area of guaranteed accuracy(W x L) (when using the basket) | 47 in x 16.40 ft (1194 mm × 5 m) (*1) | |||
| Mountable media width | Min. 4.72 in to Max. 53 in (Min.120 mm to Max. 1346 mm) | |||
| Number of push rollers | 4 rollers | |||
| Maximum cutting speed | 1000 mm/s, at 45º angle | |||
| Maximum acceleration | 13.9 m/s2, at 45º direction | |||
| Maximum cutting force | 4.41 N (450 gf) in 38 steps | |||
| Minimum character size | Approx. 5 mm alphanumeric (varies depending on character font and type of media) | |||
| Programmable resolution | GP-GL: 0.1 / 0.05 / 0.025 / 0.01 mm, HP-GL™: 0.025 mm | |||
| Repeat-ability | Max. 0.1 mm in plot up to 2 m (*1) | |||
| Mountable number of tools | 1 tool | |||
| Blade type | Supersteel | |||
| Pen type | Oil-based ballpoint, Water-based fiber-tip pen | |||
| Media type | Self-adhesive marking film (vinyl, fluorescent, reflective) excluding high-intensity reflective film, up to 0.25 mm thickness Polyester film, up to 0.25mm thickness (unguaranteed accuracy) | |||
| Interface | RS-232C, USB2.0 | |||
| Buffer memory | 2 MB | |||
| Command sets | GP-GL / HP-GL™ emulation (Set by command or auto-detect) | |||
| Display | Graphic type LCD with back-light (240dots x 128dots), supports 10 languages | |||
| Registration mark sensing system | Marks are scanned by an optical sensor (ARMS5.0), Segment area and Multiple marks compensation, 4-points axis alignment, Auto mark detect |
|||
| Alignment accuracy | Maximum 0.3 mm with printed image (when reading registration marks specified by this machine) | |||
| Power source | 100 to 120, 200 to 240 V AC (Auto switch), 50 / 60 Hz | |||
| Power consumption | 120 VA | |||
| Operating environment | 10 to 35 ºC, 35 to 75 % R.H. (non-condensing) | |||
| Guaranteed accuracy environment | 16 to 32 ºC, 35 to 70 % R.H. (non-condensing) | |||
| External dimensions (W x D x H) | Approx. 60.67 x 28.97 x 49.21 in (1541 × 736 × 1250 mm) | |||
| Weight | Approx. 89.28 lb (40.5 kg) including stand 36.11 lb (16.4 kg) | |||
| Compatible OS (*2) | Windows 10 / 8.1 / 8 / 7 Mac OSX 10.6 - 10.14 |
|||
| Supported software | Cutting Master 4, Graphtec Pro Studio (for Windows), Graphtec Studio (for Mac), Windows driver, Cutting Plotter Controller |
|||
| Compatibility Standards | Safety | UL / cUL, CE mark, RoHS Directive | ||
| EMC | VCCI Class A, FCC Class A, EN55022 Class A | |||
