The Graphtec CE7000-130AKZ cutter has been specifically designed for the aftermarket automotive industry. Modified for the streamlined cutting of Window Tint Film, Paint Protection Film, Paint Masking, Pinstriping Graphics and similar applications, this versatile cutter will boost your productivity to the next level. A heavy duty precision servo motor delivers accurate cutting speeds of up to 39 inches per second with an unsurpassed 15 feet of tracking.
CE7000-130AKZ HIGHLIGHTED FEATURES:
• Impressive 450 Grams of Downforce!
• Blazing Fast 39 Inches-per-second Cutting Speed
• Precise Loupe for Easy Blade Adjustment
• Open Software Platform
• Ethernet Connectivity
• USB Thumb Drive Connectivity - No Computer Needed!
The CE7000-130AKZ boasts our Popular Cutting Channel to allow easy perforated cut or through cut operations. This powerful cutter comes with our full complement of Graphtec Software including Cutting Master 4 plug in for Adobe and Corel Users and our ever-popular Graphtec Pro Studio software for design and cut graphics. CE7000 series works with both PC and MAC platforms or use the handy new USB Thumb Drive Port if needed.
Graphtec makes everything EASY, so contact your nearest Authorized Reseller today!
FEATURES
Datalink Barcode
Save time and reduce the chance of production errors by using barcodes to automatically process multiple jobs at the touch of a button.
DataLink supports any combination of RIP software & printer in addition to included Cutting Master 4 and Graphtec Pro Studio software.
The CE7000 detects barcode-linked cutting data from the operator's PC or USB flash memory, opens the correct file, sets the cutting conditions, and starts cutting automatically.
Contour &
die cut
Separate tool positions for contour and die cutting ensures the longevity of your blades and cutting strip when creating decals and graphics that are effortlessly popped out of sheet and roll media.
arms 8.0
A new and improved Advanced Registration Mark Sensing System, or ARMS, for print and cut applications. The DataLink Barcode system is the new addition to ARMS. Barcodes may now be generated and printed as part of the design which creates a hand’s free operation. The reading of Registration marks is faster increasing productivity.
NETWORK CONNECTION
A network connection is now possible through a network interface enabling the use of TCP/IP protocols to transfer cut data.
USB Offline Operation
A new secondary USB port has been added for placing thumb drives so jobs can be uploaded and cut without the need of a computer. Select barcode function or select file directly from the thumb drive.
SPECIFICATIONS
| Item | CE7000-130AKZ | |||
|---|---|---|---|---|
| Configuration | Grit roller with digital servo drive system | |||
| Maximum Cutting Area (W x L) | 50" x 164' |
|||
| Mountable Media Width | 2" to 60" | |||
| Number of push rollers | 4 rollers | |||
| Maximum cutting speed | 39"/s, at 45º direction | |||
| Maximum Acceleration | 45.60' (13.9 m/s2), at 45º direction | |||
| Maximum Cutting Force | 4.41 N (450 gf) in 38 steps | |||
| Minimum character size | Approx. 5 mm (0.016") alphanumeric (varies depending on character font and type of media) | |||
| Programmable Resolution | GP-GL: 0.1 / 0.05 / 0.025 / 0.01 mm, HP-GL™: 0.025 mm | |||
| Mountable number of tools | 1 tool | |||
| Blade type | Supersteel | |||
| Media type | Self-adhesive marking film (vinyl, fluorescent, reflective) excluding high-intensity reflective film, up to 25 mil (.63mm) | |||
| Interface | USB 2.0 (Full Speed), Ethernet 10BASE-T/100BASE-TX |
|||
| Buffer Memory | 2 MB | |||
| Command Sets | GP-GL / HP-GL™ (Set by command or auto-detect) | |||
| Display | Graphic type LCD with back-light (240dots x 128dots), supports 10 languages | |||
| Registration Mark Sensing System |
Marks are scanned by an optical sensor (ARMS8.0), Segment area and Multiple marks compensation, 4-points axis alignment, Auto mark detect | |||
| Alignment Accuracy | Maximum 0.3 mm with printed image (when reading registration marks specified by this machine) |
|||
| Power source | 100 to 120, 200 to 240 V AC (Auto switch), 50 / 60 Hz | |||
| Power consumption | 120 VA | |||
| Operating environment | 10 to 35 ºC, 35 to 75 % R.H. (non-condensing) | |||
| Guaranteed Accuracy Environment | 16 to 32 ºC, 35 to 70 % R.H. (non-condensing) | |||
| External dimensions (W x D x H) | 67" x 45.2" x 48" | |||
| Weight: | 121 lbs (54.9 kg) | |||
| Compatible OS (*2) | Windows 11 /10 / 8.1 / 64-bit editions Mac OS 10.2 (Sierra) to 13 (Ventura) |
|||
| Included software (download) | Graphtec Studio 2, Cutting Master 5 for Windows and Mac | |||
| Compatibility Standards | Safety | PSE, UL/cUL, CE mark | ||
| EMC | VCCI Class A, FCC Class A, CE mark | |||
ACCESSORIES
| Item | Qty | Description | |
|---|---|---|---|
| USB Cable | 1 | 9.5 feet long | |
| Cutting Blade Holder | 1 | PHP33-CB09N-HS | |
| Cutting Blade | 1 | CB09UB | |
| Cutting Blade | 1 | CB09UB-K60-2pack | |
| Loupe | 1 | PM-CT-001 | |
| Fiber-tip pen holder | 1 | PHP31-FIBER | |
| Water-based fiber-tip pen |
1 | KF700-BK (black) | |
| Stand | 1 | Parts kit | |
| Media Basket | 1 | PG0104 | |
| Anti-Static Strings with Magnets |
2 | 51409-060A | |
| Stand for CE7000 | 1 | Standard accessory for 60/130 | |
| DVD-ROM | 1 | User manual, Windows driver,
Graphtec Pro Studio (Windows, 1 license), Graphtec Studio (Mac), Cutting Master4 |
|
| Printed Documents | 1 | Setup Manual, Cutting Blade Manual, and Safety Manual | |
BROCHURE
CE7000 Brochure
VIDEO TRAINING
Graphtec Video Training is a comprehensive series of instructional videos that are key to fully understanding the versatility of the CE7000 Series Cutters. Advanced Features and Optional Accessories are also demonstrated in depth, so you can be fully trained and ready to boost productivity by mastering all the capabilities of this versatile cutter.
The Tutorial Section of our website contains all CE7000 TRAINING VIDEOS along with instructional videos for our entire line of products. The Graphtec Video Library is also available for viewing on our YouTube Channel.
